Features:
1. According to DIN 46235, good quality.
2. Clear markings on barrel to indicate correct crimping location.
3. Material: Cu≥99.9%
4. Surface: electro tin plated
|
Item No. |
Φ±0.5 | D±0.5 | d±0.5 | L±2 | C1±0.5 | C2±0.5 | W±1.5 |
| AUS-10 | Φ6.5, Φ8.5 | 6.5 | 5.0 | 29.0 | 8 | 8 | 9.5 |
| AUS-16 | Φ6.5, Φ8.5 | 8.0 | 6.0 | 36.5 | 10 | 10 | 11.5 |
| AUS-25 | Φ6.5, Φ8.5,Φ10.5 | 10.5 | 8.0 | 36.5 | 12 | 12 | 15.3 |
| AUS-35 | Φ8.5,Φ10.5 | 12.5 | 9.5 | 41.5 | 13 | 13 | 18.0 |
| AUS-50 | Φ8.5,Φ10.5, Φ12.5 | 14.5 | 11.0 | 54.0 | 15 | 15 | 20.5 |
| AUS-70 | Φ8.5,Φ10.5, Φ12.5 | 16.5 | 13.0 | 57.0 | 15 | 15 | 24.0 |
| AUS-95 | Φ10.5, Φ12.5,Φ14.5 | 19.0 | 14.5 | 63.0 | 15 | 15 | 27.5 |
| AUS-120 | Φ10.5, Φ12.5,Φ14.5 | 20.5 | 16.0 | 68.0 | 16 | 16 | 30.0 |
| AUS-150 | Φ10.5, Φ12.5,Φ14.5 | 23.5 | 18..0 | 79.0 | 16 | 16 | 34.0 |
| AUS-185 | Φ10.5, Φ12.5,Φ14.5 | 26.0 | 20.5 | 82.0 | 17 | 17 | 38.0 |
| AUS-240 | Φ10.5, Φ14.5 | 28.0 | 22.5 | 90.0 | 21 | 21 | 41.0 |
| AUS-300 | Φ16.5 | 30.0 | 23.5 | 99.0 | 21 | 21 | 43.0 |
